Victron energy BlueSolar MPPT 150/35 User Manual

9. Technical specifications
9.1. Specifications 150/35 and 150/45
MPPT 150/35 MPPT 150/45
Battery voltage 12V / 24V / 48V Auto select, 36V: Manual select
Maximum battery current 35A 45A
Nominal PV power, 12V
1a,b
500W 650W
Nominal PV power, 24V
1a,b
1000W 1300W
Nominal PV power, 36V
1a,b
1500W 1950W
Nominal PV power, 48V
1a,b
2000W 2600W
Max. PV short circuit current
2
35A 45A
Maximum PV open circuit voltage 150V
Peak efficiency 98%
Self-consumption 12V: 20mA / 24V: 15mA / 48V: 10mA
Charge voltage 'absorption' Default setting: 14.4V / 28.V / 43.2V 57.6V (adjustable)
Charge voltage 'float' Default setting: 13,8V / 27,6V 14.4V / 55,2V (adjustable)
Charge voltage ‘equalization’ 3) Default setting: 16.2V / 32.4V / 48.6V / 64.8V (adjustable)
Charge algorithm Multi-stage adaptive (eight pre-programmed algorithms) or user defined algorithm
Temperature compensation -16mV/°C / -32mV/°C / -64mV/°C
Protection PV reverse polarity, output short circuit, over-temperature
Operating temperature -30°C to +60°C (full rated output up to 40°C)
Humidity 95%, non-condensing
Maximum altitude 5000m (full rated output up to 2000m)
Environmental condition Indoor type 1, unconditioned
Pollution degree PD3
Data communication VE.Direct
4
ENCLOSURE
Colour Blue (RAL 5012)
Power terminals 16mm² / AWG6
Protection category IP43 (electronic components), IP22 (connection area)
Weight 1.25kg
Dimensions h x w x d 130 x 186 x 70 mm
STANDARDS
Safety EN/IEC 62109-1/ UL 1741 / CSA C22.2 NO.107.1-16
1a) The solar charger will limit input power if more PV power is connected.
1b) The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V.
2) A higher short circuit current may damage the solar charger in case of reverse polarity connection of the PV array.
3) Equalization is by default disabled.
4) For more information on data communication see the data communication paper in the Technical information section on
our website.
9.2. Dimension drawings
MPPT solar charger manual
Page 59 Technical specifications

Victron energy BlueSolar MPPT 150/35 Specifications

General

Model	BlueSolar MPPT 150/35
Category	Controller
Maximum PV open circuit voltage	150 V
Maximum output current	35 A
Efficiency	98%
Protection category	IP22
Humidity	95%, non-condensing
Battery voltage	12/24/48V
Self consumption	10mA
Operating temperature	-30°C to +60°C
Bluetooth compatibility	Yes, via optional VE.Direct Bluetooth Smart dongle
Protection	Short circuit, reverse polarity
