Victron energy BlueSolar PWM-Pro SCC010010010 User Manual

3
EN NL FR DE ES SE
Indicator Status Description:
Green Off
No voltage from solar
array (night time)
Green On Solid
Low voltage from solar
array (low irradiance)
Green Slowly Flashing Charging
Green On Solid
Normal
(Vbat > 12,1V resp.
24,2V)
Green Slowly Flashing Full
Green Fast Flashing Over voltage
(Vbat > 15V resp. 30V)
Orange On Solid Under voltage
(Vbat <12,5V resp. 23V)
Red On Solid Battery over discharged
(Vbat < 10V resp. 20V)
Red Flashing
Battery over
temperature
(if temp. sensor
installed)
(Tbat > 45°C)
Red
On Solid
Normal
Red
Slowly Flashing
Overload
Red
Fast Flashing
Short circuit
Charging, load and battery indicator (red)
flashing simultaneously
System voltage error
Charging, load and battery indicator
(orange) flashing simultaneously
Over temperature
Switch Button Functions:
Manual ON/OFF load control.
Resume to normal operation after a fault has been cleared.
