Only experienced users should configure or edit user defined battery charge algorithms. A wrongly defined
battery charge algorithm can lead to battery damage or create unsafe situations.
To Modify a basic battery charge algorithm:
• Select a preset battery type that is the best match to your battery type.
• Change one of the basic charge parameters that are listed on the settings screen.
• Configure the required parameters.
• The battery preset is now set to "user defined".
To Modify an expert battery charge algorithm
• Enable "Expert" mode.
• The basic and additional charge parameters are now listed on the screen.
• Configure the required parameters.
• The battery preset is now set to "user defined".
To create and save a custom battery type:
• Select a preset battery type that is the best match to your battery type.
• Change the charge parameters so they match your battery. This can be done either in normal mode or in expert mode.
• The battery preset is now set to "user defined".
• Select in the "Battery preset" menu "Create preset".
• Give the preset battery a name.
To load a custom battery type:
• Select in the "Battery preset" menu "Select preset".
• The menu lists all factory preset and custom battery types that were previously added (if any).
• Select the battery type of your choice.
To modify (or delete) a custom battery type:
• Select in the "Battery preset" menu "Edit presets"
• Navigate to the battery you want to modify. It is not possible to modify a factory preset, only custom types can be modified (or
deleted).
• Modify the charge parameters.
MPPT solar charger manual
Page 20 Configuration and settings
