10. Technical specifications
10.1. Specifications 150/70, 150/85 and 150/100
150/70 150/85 150/100
Battery Voltage 12/24/48V auto select, 36V: manual select
Maximum battery current
1a,b
70A 85A 100A
Nominal PV power, 12V
1a,b
1000W 1200W 1450W
Nominal PV power, 24V
1a,b
2000W 2400W 2900W
Nominal PV power, 36V
1a,b
3000W 3600W 4350W
Nominal PV power, 48V
1a,b
4000W 4900W 5800W
Max. PV short circuit
current
2,3
50A 70A
Max. PV Open circuit
Voltage
150V absolute maximum coldest conditions
145V start-up and operating maximum
Peak efficiency 98%
Self-consumption 12V: less than 35mA / 48V: less than 20mA
Charge voltage 'absorption' Default setting: 14.4V / 28.8V / 57.6V (adjustable)
Charge voltage 'float' Default setting: 13.8V / 27.6V / 55,2V (adjustable)
Charge voltage 'equalize'
4
Default setting: 16.2V / 32.4V / 64.8V (adjustable)
Charge algorithm multi-stage adaptive (eight pre-programmed algorithms) or user defined algorithm
Temperature compensation -16mV/°C / -32 mV/°C / -48 mV/°C / -64 mV/°C
Protection PV reverse polarity / Output short circuit / Over temperature
Operating temperature -30°C to +60°C (full rated output up to 40°C)
Humidity 95%, non-condensing
Maximum altitude 5000m (full rated output up to 2000m)
Environmental condition Indoor, unconditioned
Pollution degree PD3
Data communication VE.Can ports
5
VE.Direct port
5
Bluetooth, via the VictronConnect app
Remote on/off Yes, 2 pole terminal
Programmable relay DPST AC rating: 4A up to 240Vac / DC rating: 4A up to 35Vdc, 1A up to 60Vdc
Parallel operation Yes, parallel synchronised operation via VE.Can (max. 25 units) or via Bluetooth, (max. 10
units).
ENCLOSURE
Colour Blue (RAL 5012)
PV terminals Tr models: 35 mm² / AWG2
MC4 models: 2 pairs of
MC4 connectors
3,6
Tr models: 35 mm² / AWG2
MC4 models: 3 pairs of MC4 connectors
3,6
Battery terminals 35 mm² / AWG2
Protection category IP43 (electronic components), IP22 (connection area)
MPPT solar charger manual
Page 62 Technical specifications
