Videx 4000 Series Manual

66250203 - V4.4 - 15/05/22
- 8 -
4000 Series Vandal Resistant Range
Art.4212 - Installation instructions
HOME PARAMETERS
Home par. menu Parameter Name Programming method Permission Default value
1: Line 1 Line 1 By panel and PC software All /
2: Line 2 Line 2 By panel and PC software All /
3: Line 3 Line 3 By panel and PC software All /
4: Home 2 Home 2 By panel and PC software All Disabled
5: Switch Time Switch time By panel and PC software All 2 s
LINE 1, 2, 3
Each line can be up to 16 characters long and will appear on the
main screen in standby. Enter the string and press
. The have
a blank line enter one or more space characters.
Modify routine
• press “1”, “2” or “3” to enter into edit mode;
• enter the string;
• press
to save or to delete characters or exit edit mode
without saving.
HOME 2
To enable a second screen which can display a logo.
Modify routine
• press “4” button to enter into edit mode;
• press “4” to enable or disable;
• press
to save or to exit edit mode without saving.
SWITCH TIME
Time delay when switching between the two main screens.
Modify routine
• press “5” to enter into edit mode;
• enter time is seconds: it must be between “1“ and “250”;
• press
to save or to delete characters or exit edit mode
without saving.
TIME PARAMETERS
Time par. menu Parameter Name Programming method Permission Default value
1: Clock Clock format By panel and PC software All 0-23
Clock By panel and PC software All /
BST/GMT Enable/disable By panel All Enabled
2: Date Date format By panel and PC software All European
Date By panel and PC software All /
Day By panel All /
3: Trade Trade enable By panel and PC software All Disabled
Trade start By panel and PC software All /
Trade end By panel and PC software All /
4: Relay Time Relay time By panel and PC software Only Engineer 2 s
5: Speech Time Speech time By panel and PC software Only Engineer 120 s
CLOCK FORMAT
It changes the clock format shown on the home page.
Select either 12 hour or 24 hour clock format.
Modify routine
• press “1” to enter the clock menu;
• press “1” to enter into edit mode;
• press “1” to switch from 1-12 to 0-23 and viceversa;
• press
to save or to exit edit mode without saving.
CLOCK
Set the time on the door panel.
Modify routine
• press “1” to enter the clock menu;
• press “2” to enter edit mode;
• enter the hour, minutes and seconds (all elds are composed of
two digits). After entering two digits to set the hour it automat-
ically advances to the minutes and then to seconds.If in 12 hour
clock format, after seconds it is possible to select AM/PM;
• After setting the last parameter the time will be saved.
Art.4212 Audio/video digital front panel Programming

Videx 4000 Series Specifications

General

Series	4000 Series
Category	Intercom System
Material	Stainless Steel
Operating Voltage	12V DC
Housing Material	Stainless steel
Compatibility	Compatible with Videx audio and video internal units
