Märklin-Motorola-Decoder:
The address of older locomotive deco-
der with the Märklin-Motorola format is
adjusted by Dual Inline switches (DIP-
switches). The Commander shows you
graphically how to adjust the switches
for the respective address, in the
Märklin-Motorola-protocol.
• Press the key “Save” in order to save
the complete new data-record of the
locomotive and to charge it in the loco-
motive-data record of the Commander.
• Don’t forget to register the adjusted
data in the locomotive decoder too.
• You close the menu by a touch on the
“Exit”-key in the bottom right-hand
corner.
Touch elds:
Read selected data of the
locomotive decoder
Transmit selected data to
the locomotive decoder
Entering-mode of a text
Entering-mode of numbers
and special characters
Delete entry
Finish, con rm input
Save complete data record
in the Commander
Exit menu
Remark on the additional
functions:
You have different additional functions to
your disposal, as light, sound, movement
etc, depending on the locomotive model or
the decoder type. The ve priority-function
keys are always displayed and thus imme-
diately accessible.
All other additional functions are selected
by the “F►” touch eld.
You can edit the additional functions with
the index card 2 of the locomotive editor.
The index card has three sections. On the
left you see a list of all possible additio-
nal functions. With the navigator you scroll
through the list.
All available function keys are listed in the
middle part.
The ve priority-function keys that are al-
ways displayed on the control panel in
order to have an immediate access are
shown on the right hand side.
