The following adjustment options are at
your disposal:
Symbol-Type: The Commander shows
you the respective symbol of the track
diagram.
Address: Touch slightly the address eld
and enter a standard address-value by the
keyboard on the touch screen (Please
refer to the operating instruction of the
decoder). You can delete your input with
“CL” and con rm it with “OK”.
Adjusting the outputs of the decoder:
You can reverse the outputs of an incorrect
connected switch motor so it acts
reversed.
Indication: You can adapt the representa-
tion of the turnout to the track diagram.:
Turnout driving unit: You can choose
between a conventional solenoid-drive and
a servo drive. The selected drive unit type
can be con gured individually now,
depending on your choice.
On the next page of the menu you adjust
the format of the digital system and you
determine if the decoder executes a
particular switching command every
time the system starts.
• Enter the wished adjustments.
• To nish, touch the key “Save” in order
to save the complete data record of the
respective accessory on the
Commander.
• You close the menu by pushing “Exit”.
You can modify your adjustments at
any time by calling up the menu again.
Connection to the track power:
Connect the decoders (accessories with
solenoid drive and signal-decoder) to the
red and brown connections of the track
power according to the decoder operating
instruction. Carry out the decoder
programming procedure according to the
operating instruction..
DCC-decoder:
Activate the programming mode of the
decoder. Touch the respective touch
eld of the track diagram and operate
the switch. The Commander transmits a
control command to the corresponding
address. The decoder saves the recei-
ved address as its own.
Alternative you can directly enter a con-
trol command to the chosen address in
the “direct mode”, on condition that the
decoder is in the programming mode.
Most of the decoder con rm the trans-
mission of the address by the execution
