VITOCELL 300-B
The Vitocell 300-B is a dual mode DHW
cylinder with two indirect coils. Made from
high alloy stainless steel, the Vitocell 300-B
is a reliable and efficient solution for the
integration of two energy sources.
The cylinders are available in two sizes,
either 300 litres or 500 litres.
Vitocell 200-B and 300-B
Twin coil
Volumes litres 300/500 210/250/300
Material SS 1.4571 SS Duplex
Thickness/gauge mm 2.8 1
Max. pressure bar 16 10
Operating pressure bar 10 3
Insulation PUR PUR
Heat loss in 24h kW 1.17 1.9
Height mm 1 790 2 020
Width/diam. mm 633 550
Overall width mm 700 600
Immersion heater 3/5 (400V) 3 (230V)
Warranty years 2 25
Coil rating kW 54 19
Weight (net) kg 100 46
Expansion vessel type litres Ex. Vessel Ex. Vessel
Vitocell 300-B 300 Vitocell 200-B 300
Vitocell 300-B
