Overview of settings and adjustments
Setting Function Grid movement Range
Outside Temperature
Fixed Point
The outside temperature at which the
control emerges out of WWSD and resumes
regular operation
Left and right 34ºF to 86ºF /
1ºC to 30ºC
Flow Temperature Fixed
Point
The supply temperature calculated when the
control emerges out of WWSD and resumes
regular operation
Up and down 34ºF to 212ºF /
1ºC to 100ºC
Outside Temperature
Climazone
The outside temperature at which the
control calculates the maximum supply
temperature
Left and right 32ºF to -4ºF /
0ºC to -20ºC
Flow Temperature
Climazone
The maximum supply temperature
calculated based on the outside temperature
climazone setting
Up and down 34ºF to 212ºF /
1ºC to 100ºC
Normal Room
Temperature
Provides a parallel shift of curve based on
outside temperature fixed point
Diagonal
movement of
heating curve
slope
41ºF to 104ºF /
5ºC to 40ºC
Flow Temperature
Minimum
Minimum supply temperature setting Up and down 34ºF to 165ºF /
1ºC to 74ºC
Flow Temperature
Maximum
Maximum supply temperature setting Up and down 34ºF to 165ºF /
1ºC to 74ºC
