PC Timing Reference Chart
VGA Timing Panel FullHD (1920 x 1080) Support
No Mode Resolution
H sync
(kHz)
V sync
(Hz)
Pixel clock
(MHz)
Polarity Support
1 IBM VGA 720 x 400 31.47 70.09 28.32 N/P V
2 VESA DMT 640 x 480 31.5 59.94 25.175 N/N V
3 VESA DMT 800 x 600 37.88 60.32 40 P/P V
4 VESA DMT 1024 x 768 48.36 60 65 N/N V
5 VESA DMT 1280 x 768 47.77 59.8 79.5 N/P V
6 VESA DMT 1280 x 800 49.7 59.81 83.5 N/P V
7 VESA DMT 1280 x 1024 63.98 60.02 108 P/P V
8 VESA DMT 1360 x 768 47.71 60.01 85.5 P/P V
9 VESA DMT 1440 x 900 55.94 59.89 106.5 N/P V
10 VESA DMT 1680 x 1050 65.29 59.95 146.25 N/P V
11 CEA 1920 x 1080 67.5 60 148.5 P/P V
☼
This VGA input does not support interlaced signals.•
