Other Information
36
7 07
8 08
9 09
0 0A
- 0B
RECALL (LAST) 0C
0D
0E
ASPECT (ZOOM) 0F
VOLUME UP (+) 10
VOLUME DOWN (-) 11
MUTE 12
CHANNEL/PAGE UP (+) 13
CHANNEL/PAGE DOWN (-) 14
POWER 15
SOURCES (INPUTS) 16
17
18
SLEEP 19
MENU 1A
UP 1B
DOWN 1C
LEFT 1D
RIGHT 1E
OK (ENTER) 1F
EXIT 20
21
22
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
[NOTE]
1. This IR-pass-through code is different with RCU key code
2. Special control sequence for POWER key under IR-pass through mode.
2-1. When display is OFF and receives the POWER code : The display will turn on itself, then forward
the POWER code to the host via RS232.
2-2.
3. The code of VOLUME UP and VOLUME DOWN will repeatedly output when press and hold the keys.
When display is ON and receives the POWER code : The display will forward the POWER code
to the host via RS232, then turns off itself
.
