ViewSonic PJD5126 User Manual

1
Table of contents
Important safety
instructions .......................2
Introduction......................4
Projector features .................................4
Shipping contents.................................5
Projector exterior view.........................6
Controls and functions .........................7
Positioning your
projector..........................12
Choosing a location............................ 12
Projection dimensions........................ 13
Connection......................17
Connecting a computer or monitor .... 18
Connecting Video source devices...... 19
Operation........................22
Starting up the projector.....................22
Using the menus.................................23
Utilizing the password function......... 24
Switching input signal........................27
Adjusting the projected image ........... 28
Magnifying and searching for details. 29
Selecting the aspect ratio ................... 30
Optimizing the image......................... 32
Setting the presentation timer ............ 36
Hiding the image................................37
Locking control keys..........................37
Freezing the image............................. 37
Operating in a high altitude
environment .......................................37
Creating your own startup screen....... 38
Controlling the projector through
a LAN environment........................... 39
Using the projector in standby mode. 45
Shutting down the projector .............. 45
Menu operation.................................. 46
Maintenance ...................56
Care of the projector.......................... 56
Lamp information.............................. 57
Troubleshooting .............63
Specifications..................64
Projector specifications...................... 64
Dimensions ........................................ 66
Ceiling mount installation ................. 66
Timing chart ...................................... 67
Copyright information...69
Appendix.........................70
IR control table.................................. 70
RJ45 response table ........................... 72
RS232 command table....................... 72

ViewSonic PJD5126 Specifications

General

Native aspect ratio	16:9
Projection distance	1.2 - 10 m
Vertical scan range	50 - 120 Hz
Projection technology	DLP
Supported aspect ratios	4:3, 16:9
Contrast ratio (dynamic)	15000:1
Contrast ratio (typical)	-
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Focus	Manual
Throw ratio	1.86 - 2.04:1
Zoom capability	Yes
Focal length range	- mm
Lamp power	180 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, SECAM
RMS rated power	2 W
Number of built-in speakers	1
Built-in display	No
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Noise level	32 dB
Certification	CB, UL, cUL, FCC (including ICES-003), CE, UL-Argentina, NOM, GS, GOST-R, SASO, Ukraine, PSB, C-Tick, Korean-KC, CCC, CECP, WEEE
Noise level (economic mode)	29 dB
Product color	Black
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	243 W
Operating altitude	1800 - 3048 m
Storage temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	RoHS, ENERGY STAR

Weight and Dimensions

Depth	242 mm
Width	294 mm
Height	84 mm
Weight	2600 g
Package depth	192 mm
Package width	380 mm
Package height	345 mm
Package weight	4100 g
