3
13. Do not block the ventilation holes. If the ventilation holes are seriously obstructed,
overheating inside the projector may result in a fire.
- Do not place this projector on a blanket, bedding or any other soft surface.
- Do not cover this projector with a cloth or any other item.
- Do not place inflammables near the projector.
14. Always place the projector on a level, horizontal surface during operation.
- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of
more than 15 degrees front to back. Using the projector when it is not fully horizontal
may cause a malfunction of, or damage to, the lamp.
15. Do not stand the projector on end vertically. Doing so may cause the projector to fall
over, causing injury or resulting in damage to the projector.
16. Do not step on the projector or place any objects upon it. Besides probable physical
damage to the projector, doing so may result in accidents and possible injury.
17. Do not place liquids near or on the projector. Liquids spilled into the projector may
cause it to fail. If the projector does become wet, disconnect it from the power
supply's wall socket and call your local service center to have the projector serviced.
18. This product is capable of displaying inverted pictures for ceiling mount installation.
Use only qualified ceiling mount kit for mounting the projector and ensure it is
securely installed.
19. When the projector is under operation, you may sense some heated air and odor from
its ventilation grill. It is a normal phenomenon and not a product defect.
20. Do not use the Security bar for transporting or installation. It should be used with a
commercially available theft prevention cable.
Safety instructions for ceiling mounting of the
projector
We want you to have a pleasant experience using your projector, so we need to bring this
safety matter to your attention to prevent damage to person and property.
If you intend to mount your projector on the ceiling, we strongly recommend that you use a
proper fitting projector ceiling mount kit and that you ensure it is securely and safely
installed.
If you use an inappropriate projector ceiling mount kit, there is a safety risk that the
projector may fall from the ceiling due to an improper attachment through the use of the
wrong gauge or length screws.
You can purchase a projector ceiling mount kit from the place you purchased your projector.
We recommends that you also purchase a separate Kensington lock compatible security
cable and attach it securely to both the Kensington lock slot on the projector and the base of
the ceiling mount bracket. This will perform the secondary role of restraining the projector
should its attachment to the mounting bracket become loose.

Table of Contents

Other manuals for ViewSonic PJD5126

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ViewSonic PJD5126 and is the answer not in the manual?

ViewSonic PJD5126 Specifications

General IconGeneral
Native aspect ratio16:9
Projection distance1.2 - 10 m
Vertical scan range50 - 120 Hz
Projection technologyDLP
Supported aspect ratios4:3, 16:9
Contrast ratio (dynamic)15000:1
Contrast ratio (typical)-
Screen size compatibility30 - 300 \
Projector native resolutionSVGA (800x600)
FocusManual
Throw ratio1.86 - 2.04:1
Zoom capabilityYes
Focal length range- mm
Lamp power180 W
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)6000 h
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, SECAM
RMS rated power2 W
Number of built-in speakers1
Built-in displayNo
HDMI ports quantity0
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity3
Component video (YPbPr/YCbCr) in2
Connectivity technologyWired
Noise level32 dB
CertificationCB, UL, cUL, FCC (including ICES-003), CE, UL-Argentina, NOM, GS, GOST-R, SASO, Ukraine, PSB, C-Tick, Korean-KC, CCC, CECP, WEEE
Noise level (economic mode)29 dB
Product colorBlack
Market positioningPresentation
Cable lock slot typeKensington
Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)1 W
Power consumption (typical)243 W
Operating altitude1800 - 3048 m
Storage temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Sustainability certificatesRoHS, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth242 mm
Width294 mm
Height84 mm
Weight2600 g
Package depth192 mm
Package width380 mm
Package height345 mm
Package weight4100 g
