Vighnaharta TSGR-21 - Page 16

TSGR-21 GAS Release Panel User Manual
Vighnaharta Technologies Pvt. Ltd. Page 16 of 43
Pin No.
Connection
Name
Description
J11.1
NAC 1 +
NAC1 Positive(+)
J11.2
NAC 1 -
Ground/NAC1 Negative(-)
J11.3
NAC 2 +
NAC2 Positive(+)
J11.4
NAC 2 -
Ground/NAC2 Negative(-)
J11.5
NAC 3 +
NAC3 Positive(+)
J11.6
NAC 3 -
Ground/NAC3 Negative(-)
RAC1
J14.1
RAC1+
RAC1 Positive(+)
J14.2
RAC1-
RAC1 Negative(-)
RAC2
J14.3
RAC2+
RAC2 Positive(+)
J14.4
RAC2-
RAC2 Negative(-)
Smoke Detector Zones
J3.1
Zone1+
Zone1 Positive(+)
J3.2
Zone1-
Zone1 Negative(-)
J3.3
Zone2+
Zone2 Positive(+)
J3.4
Zone2-
Zone2 Negative(-)
PFC Outputs
J13.1
NO
Normally Open of Fire Status Output
J13.2
C
Common for Fire Status Output
J13.3
NC
Normally Closed of Fire Status Output
J13.4
NO
Normally Open of Prg. Relay1 Status Output
J13.5
C
Common for Prg. Relay1 Status Output
J13.6
NC
Normally Closed of Prg. Relay1 Status Output
J13.7
NO
Normally Open of Prg. Relay1 Status Output
J13.8
C
Common for Prg. Relay1 Status Output
J13.9
NC
Normally Closed of Prg. Relay1 Status Output
Digital Inputs
J4.1
Rel.
Input for RAC1 Release
J4.2
GND
Ground
J4.3
Abort
Input for RAC1 Abort
J4.4
PS.1
Input for Pressure1
J4.5
GND
Ground
J4.6
PS.2
Input for Pressure2
J4.7
ACT.1
Actuator Input 1
J4.8
GND
Ground
J4.9
ACT.2
Actuator Input 2
J4.10
Rmt. I/P +
Digital Remote Input+
J4.11
Rmt. I/P -
Digital Remote Input-
J4.12
DI 1
Extra Digital Input 1 (Not used)
J4.13
DI 2
Extra Digital Input 2 (Not used)
