TSGR-21 GAS Release Panel User Manual

Vighnaharta Technologies Pvt. Ltd. Page 9 of 43

• More than 200 records history events for fire alarm, fault condition, RAC release or abort

condition, sequence of events.

1.3 Technical Specifications

Power Supply

180 – 265V AC, 3A, 60/50 Hz.

Input

Initiating Device Circuit (IDC)

• Voltage:24 VDC

• End of Line:4.7KΩ,1 W

• Digital Inputs: 3 inputs

Indication

Front panel LED indications

• SYSTEM ON

• MAINS FAIL

• BATTERY FAULT

• NAC FAULT

• RAC FAULT

• COMMUNICATION FAIL

• SILENCE

• REMOTE FIRE

• PRE RELEASE

• REMOTE RELEASE

• RAC ABORT

• RAC RELEASE

• Wi-Fi

• FIRE

• FAULT

• AUTO

• MANUAL

• MAINTENANCE

LED Indications for 2 zones

FIRE, SHORT FAULT, OPEN FAULT, DISABLE

16 x 2 LCD Dot Matrix Display Indication

Zone fire status, fault status, configuration menus, real time

clock
