TSGR-21 GAS Release Panel User Manual
Vighnaharta Technologies Pvt. Ltd. Page 28 of 43
6) Set ActPress Swt2:
By selecting this menu Set ActPress Swt2 switch type is selected which is going to
connect with cylinder. By default it is NO type you can select NC type to change the state press Enter
menu and the use left or right key. Press ENTER key to save the changes.
LCD Display is Shows as below.
6) Set Remote I/P:
By selecting this menu Set Remote I/P you can configure Remote I/P as RM Fire or
Silence. By default it is Remote Fire you can select Silence. To change the state press Enter menu and
the use left or right key. Press ENTER key to save the changes.
LCD Display is Shows as below.
3.2.3 Output Config:
From selecting this menu you can Enter below sub menus
1) RAC Config:
After entering in the RAC Config menu, LCD displays current setting of RAC Configuration.
In this menu, there are four options available for RAC configuration. Use left and right keys to move to next
option. To set the particular option, press ENTER key.
1. Z1 & Z2 Cross: This is the cross zoning option for RAC with only zone 1 and 2. When both zones are in
fire alarm condition then RAC will be released.
2. Z1 or Z2: This is the simple zoning option for RAC with any of the two zones. When any of the two zones
is in fire alarm condition then RAC will be released.
3. Z1 Only: This is the simple option for RAC release. When only zone 1 is in fire alarm condition then RAC
will be released.
4. Z2 Only: This is the simple option for RAC release. When only zone 2 is in fire alarm condition then RAC
will be released.
2) Cylinder Type:
After entering in the Cylinder Type menu, LCD displays current setting of Cylinder Type
