TSGR-21 GAS Release Panel User Manual
Vighnaharta Technologies Pvt. Ltd. Page 27 of 43
3.2.2 Input Config:
From selecting this menu you can Enter Below Sub Menus
1) ZONE1 Config:
By selecting this menu ZONE1 Config you can Enable or Disable (Bypass) the Zone1. By default
Zone1 is Enable to change the state press Enter menu and the use left or right key. Press ENTER key to
save the changes. If you make Zone1 disable Zone1 disable LED glows.
LCD Display is Shows as below.
2) ZONE2 Config:
By selecting this menu ZONE2 Config you can Enable or Disable (Bypass) the Zone2. By default
Zone1 is Enable to change the state press Enter menu and the use left or right key. Press ENTER key to
save the changes. If you make Zone2 disable Zone2 disable LED glows.
LCD Display is Shows as below.
3) Set Press Swt1:
By selecting this menu Set Press Swt1 switch type is selected which is going to connect with
cylinder. By default it is NO type you can select NC type to change the state press Enter menu and the
use left or right key. Press ENTER key to save the changes.
LCD Display is Shows as below.
4) Set Press Swt2:
By selecting this menu Set Press Swt1 switch type is selected which is going to connect
with cylinder. By default it is NO type you can select NC type to change the state press Enter menu and
the use left or right key. Press ENTER key to save the changes.
LCD Display is Shows as below.
5) Set ActPress Swt1:
By selecting this menu Set ActPress Swt1 switch type is selected which is going to connect
with cylinder. By default it is NO type you can select NC type to change the state press Enter menu and
the use left or right key. Press ENTER key to save the changes.
LCD Display is Shows as below.
