13. Screw the end hose connector to the rotor.
14. Insert the hose to the end hose connector.
15. Install the rotor cover and tighten its nut.
16. The rotor cover must remain parallel to the tire. Verify that the stain-
less steel pipe is not rubbing against the tire, or that it is not too far
from the tire. Adjust by modifying the position of the bend and fix
the final position by tightening the bend’s nut.
1,5 CM. (9/16”)
