information from applications and user settings to put the system as a whole into a
low-power state.
Wake-up Devices and Events
Table 9 lists the devices or specific events that can wake the computer from specific
states.
Table 9: Wake-up Devices and Events
These devices/events can wake up the computer… …from this state
LAN S1, S3, S4, S5
Modem (Back panel Serial Port A) S1, S3
PME# signal S1, S3, S4, S5
Power switch S1, S3, S4, S5
PS/2 devices S1, S3
RTC alarm S1, S3, S4, S5
USB S1, S3
Note: The use of these wake-up events from an ACPI state requires an
operating system that provides full ACPI support. In addition, software,
drivers, and peripherals must fully support ACPI wake events.
