Viking pump CMD-E02 Series - Bolt Torque Recommendations

SECTION TSM 344 ISSUE E PAGE 20 OF 24
  

 

Front Cover / Housing 10 - 32 15 20
Housing Adaptor -to- Spool 1/4 - 20 48 65
Spool -to- Motor Adaptor or Motor 3/8 - 16 72 98
Motor Adaptor -to- Motor
56C 3/8 - 16 72 98
63 B14 M5 - 0.80 24 33
80 B14 M6 - 1.00 48 65

Front Cover 1/4 - 20 48 65
Housing -to- Spool 1/4 - 20 48 65
Spool -to- Motor Adaptor or Motor 3/8 - 16 72 98
Motor Adaptor -to- Motor
56C 3/8 - 16 72 98
143TC - 182C 3/8 - 16 72 98
63 B14 M5 - 0.80 24 33
80 B14 M6 - 1.00 48 65

Front Cover 1/4 - 20 72 98
Housing -to- Spool 3/8 - 16 120 163
Spool -to- Motor Adaptor 3/8 - 16 120 163
Base Mount -to- Spool 3/8 - 16 120 163
Flange Bolts (min. to seal) Varies 120 163
Motor Adaptor -to- Motor
56C 72 98
143TC - 182C 3/8 - 16 120 163
100 - 112 B14 M8 - 1.25 120 163

Front Cover 3/8 - 16 120 163
Housing -to- Spool 3/8 - 16 120 163
Spool -to- Motor Adaptor 3/8 - 16 120 163
Base Mount -to- Spool 3/8 - 16 120 163
Flange Bolts (min. to seal) Varies 120 163
Motor Adaptor -to- Motor
143TC - 182C 3/8 - 16 120 163
182TC - 184TC 1/2 - 13 120 163
100 - 112 B14 M8 - 1.25 120 163

