Viking MT 830 - Pushing the Tractor by Hand; Attaching a Trailer

EN - 19
English
DeutschFrançais
Operating the Tractor
PUSHING THE TRACTOR BY HAND
1. Disengage the PTO and turn the engine off.
2. Move the transmission release lever up, pull back
approximately 25 mm, and press down to lock into
released position (Figure 3).
3. The tractor can now be pushed by hand.
Note: To drive the tractor, the release lever must be
moved completely forward and pushed down into locked
position.
DO NOT TOW TRACTOR
Towing the unit will cause transmission
damage.
• Do not use another vehicle to push or pull
this unit.
• Do not actuate the transmission release
valve lever while the engine is running.
Release Lever
Figure 3. Release Lever
ATTACHING A TRAILER
The maximum horizontal drawbar force allowed is 444N.
The maximum vertical drawbar force is 222N.
This equates to a 180 kg trailer on a 10° hill.
1. Align the trailer tongue (C) with the trailer hitch (A).
Secure using a clevis pin (B) and hair pin clip (D).
B
C
D
A
