Specifications
ENGINE
Engine, construction 4-stroke Briggs & Stratton internal
combusting motor
Model 311707 Intek 17 HP
Cylinder 1
Displacement 508 ccm
Performance 12,5 kW
Torque 28,7 Nm
Ignition High Energy Electronic Ignition
Electrical System 12 Volt, 3 amp Alternator Unregulated
Battery 200 Cold Cranking amps,
23 Minute Reserve Capacity
Speed of rotation
during the test 2500 rpm
TRANSMISSION
Type Hydrostatic Tuff Torq K56 FC
Pump Variable Displacement Axial Piston
Motor Fixed Displacement Axial Piston
Control Pedal Foot Control
Movement Free-Wheeling Lever for Manual Tractor
Hydraulic Fluid 10W 30 Premium Engine Oil
Speeds Forward: 0 - 8,3 km/h
Reverse: 0 - 4,8 km/h
CHASSIS
Frame Heavy Gauge Steel Channel
Engine Mounting: Above Front Axle
Pivot Point Location: Rear Carrier
Rear Wheels Tire Size: 18 x 8.50-8 Carlisle
Pneumatic Inflation Pressure:
0,69 - 0,83 bar
Front Wheels Tire Size: 15 x 6.60-6 Carlisle
Pneumatic Inflation Pressure:
0,83 - 1,04 bar
Bearings: Sintered Iron with Grease Fittings
Accessibility Hood Tips Forward, Seat Tips Forward
Fuel Tank Material: High Density Polyethylene,
Transparent
Capacity: 7,5 L
Fuel Normal unleaded
Seat Medium Back, Adjustable
Turning Radius Inside Rear Tire: 36 cm
Sound power level
(EN 84/538/EEC) 100 dB(A)
Sound pressure level
(EN 79/113/EEC) 87 dB(A) (Measured at operator’s position)
38” Mower
Vibration Data
at the steering wheel
(EN 1032, EN 1033) 8,0 m/s
2
(Test performed on a concret floor)
Vibration Data
at the seat
(EN 1032, EN 1033) 0,4 m/s
2
(Test performed on a concret floor)
Note: Specifications are correct at time of printing and are subject to change without notice.
44” Mower
Vibration Data
at the steering wheel
(EN 1032, EN 1033) 5,6 m/s
2
(Test performed on a concret floor)
Vibration Data
at the seat
(EN 1032, EN 1033) 0,3 m/s
2
(Test performed on a concret floor)
CONTROLS
Steering 38 cm Steering Wheel
Gear and Sector, 1.5 turns Lock to Lock
Clutch/ Brake Combination Clutch/Brake/Parking Brake
Pedal. Parking Brake Lock,
Foot/Hand Activated
Location Mower Height Adjustment: Right Side
PTO Clutch-Manual: Dash Panel
Ground Speed Pedal: Right Side
Ignition Key Switch: On Seat Deck
Throttle Lever & Choke Lever:
(Combined) On Dash Panel
DIMENSIONS
Tractor
Overall Length 172 cm
Overall Width 126 cm (with Deflector)
Height At Steering Wheel: 104 cm
To Top of Engine Cover: 86 cm
Wheel Base 127 cm
Weight net 225 kg (with 38” Mower)
233 kg (with 44” Mower)
38” Mower
Effective Cutting
Width 97 cm
Overall Width
with Deflector 126 cm
Cutting Height Variable between 2,5 and 9,8 cm
Weight 55 kg
Blade Arrangement Two Blades
Mower Drive V-Belt from Tractor Engine Pulley
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
Front wheels 2 adjust. gauge wheels
Rear wheels 3 settled gauge wheels
44” Mower
Effective Cutting
Width 112 cm
Cutting Height Variable between 3,8 and 9,8 cm
Weight 63 kg
Blade Arrangement Three Blades
Mower Drive V-Belt from Tractor Engine Pulley
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
Front wheels 2 adjust. gauge wheels
Rear wheels 3 settled gauge wheels
