TECHNICAL SUPPORT 1 800 908 0884
9
IMPORTANT INSTALLATION INFORMATIONIMPORTANT INSTALLATION INFORMATION
Specifications
This is NOT a pedestrian gate operator
12’ maximum gate length
500 pounds maximum gate weight
Do NOT Install the gate operator to lift gates
Locate Control Buttons:
1. Within sight of the gate,
2. At a minimum height of 5 feet so
small children are not able to
reach it, and
3. Away from all moving parts of
the gate.
Maximum Gate Length: 12 feet
Maximum Gate Weight: 500 lbs.
Maximum Aperture Angle: 130 deg.
Power Requirements: 120 VAC Single Phase at 2 Amps
Or
220 VAC Single Phase at 1 Amp
Maximum Operating Temperature:
70°C (158°F)
500 lb.
MAX.
CAUTION -
FOR USE WITH GATES OF A MAXIMUM OF 12 FT IN LENGTH AND 500 LBS. IN WEIGHT.
WARNING - TO REDUCE THE RISK OF SEVERE INJURY OR DEATH TO PERSONS:
