Viking X-9 - Accessory Connections; Open Commands; Safety Connections

ACCESSORY CONNECTIONSACCESSORY CONNECTIONS
TECHNICAL SUPPORT 1 800 908 0884
22
Vehicle loop detectors must be installed to
decrease the possibility of vehicle
entrapment on the gate (see page 20).
The SECONDARY ENTRAPMENT PROTECTION
like the edge sensor and the photoelectric
beam MUST BE PART OF EVERY SINGLE
INSTALLATION to prevent pedestrian or
animal entrapment (see pages 6 and 7).
The edge sensor and/or the photoelectric
beam must be UL325 compliant devices.
Open Commands
Sa
f
Open Commands
d
Station Sa
f
Open Commands
d
Station
Stop Open Gnd Fire Gnd Strike Gnd Exit Gnd Center
Gnd
60sec off
Exit
Loop
Detector
Fire
Override
Keypad
FIRE
Safety Connections
Safety Connector
m
ands Safety Connector
m
ands
Gnd Exit Gnd Center Gnd Safety Gnd UL Gnd +28v
Gnd
0
sec off
Center
Loop
Detector
Safety
Loop
Detector
Beam
Edge Sensor
1
2
Connection Locations
(Single Unit Board shown)
2
1
