Viking X-9 - Vehicular Loop Detector Installation; Loop Layout Diagrams

Inside
Outside
Exit Loop
Inside Safety Loop
Center Loop
Outside
Safety Loop
Inside
Outside
5'
5' 5'
AA
5'
Gate in Open Position
Inside
Safety
Loop
Center
Loop
Outside
Safety
Loop
Exit
Loop
Make Even
with Open Gate
TECHNICAL SUPPORT 1 800 908 0884
20
VEHICULAR LOOP DETECTOR INSTALLATIONVEHICULAR LOOP DETECTOR INSTALLATION
Dimension A –5’ for Single Gate Operator
6’ for Master/Slave Gate Operator
