Viking X-9 - Magnetic Lock; Solenoid; Guard Station

TECHNICAL SUPPORT 1 800 908 0884
24
The guard station provides control of the
gate operator to open, stop and close the
gate.
All three switches must be Normally Open
type of switch, and can share the same
common (ground).
Place the control switch box within sight of
the gate, away from moving parts of the
gate and out of reach of children.
Guard Station
Open Comman
d
Guard Station
S
lave Open Comman
d
Guard Station
S
lave
Stop
Open GND Close Stop Open Gnd Fire Gnd Strike Gnd
60sec
N.O.
N.O.
N.O.
COM
CLOSE
STOP
OPEN
2
External supply for the magnetic lock must
be provided. This will prevent rapid drainage
of the battery in the event of power failure.
Relay Contact 10A-250VAC
External supply for the solenoid connection
must be provided. This will prevent rapid
drainage of the battery in the event of
power failure.
Relay Contact 10A-250VAC
Magnetic Lock
Solenoid Connection
ACCESSORY CONNECTIONSACCESSORY CONNECTIONS
Radio Station
Mag.
Lock
Mag. Lock
Radio Station
d
d
io
d
8
v
8
v
Mag.
Lock
Mag. Lock
N.C.
COM
N.O.
Radio Station
Mag.
Lock
Mag. Lock
Radio Station
d
d
io
d
8
v
8
v
Mag.
Lock
Mag. Lock
N.C.
COM
N.O.
2 1
1
1
Connection Locations
(Single Unit Board shown)
