Features
Document no.
Article no.
STB-6GN_ds rev.04 2004.10.14
STB-6GN
Description:
Technical data:
STB-6GN
Command Talk-Back System
Mounting hole distance: 134 mm
144
Ø 4 mm
TALK
Mounting hole distance: 86 mm
96
for flush mounting
44 28
120
STB-6GN
* Substation with gooseneck microphone for indoor
bridge wing
* Parallel microphone / loudspeaker for ETB and CTB
operator panels
* Delivered for flush or bulkhead mounting
Dimensions (WxHxD): 144 x 96 x 44
Mounting: 4x 4mm screws
Weight: Approx. 0,850kg
Housing: Aluminium elox.
Colour: Black
IP-rating: IP-44
Cable entry: PG-16
Connections: Screw terminal
Loudspeaker: 3W
www.zenitel.biz\Communication & Security Systems\Zenitel Marine
