Installation & User Manual System CTB-100V
8
2.4.13 Hands free operation
Foot-switch
Parallel station
STB-6GN
Foot-switch Foot-switch
Handsfree operation of operation panel or parallel station.
Option 1
Operation panel with gooseneck microphone MB-30G and footswitch
U2410.
Option 2
Parallel station type STB-6GN with gooseneck microphone MB-30G and
footswitch U2410.
2.4.14 Privacy functions ubstation STB-1
Substation STB-1 is designed for indoor use; cabins, mess room etc.,
and prepared with privacy function.
It means ; Listening is not possible in the central unit from STB-1.
After a call is set up from the central unit, the operator of STB-1 have
to use TALK button for communicate with the central unit.
(STB-1 can also be set to normal talk back function, see pos.3.10)
2.4.15 Two-way voice communication, Nautical Safety
1
CENTRAL UNIT CU
JUNCTION BOX
Configuration to meet requirement for hands free
two-way voice communication according to
DNV rules for Nautical Safety.
Following locations has operation panels with all
call:
- Bridge wings
- Wheelhouse
- Engine control room
Following locations has substations and
additional all call stations:
- Forecastle deck (fore mooring station)
- Aft mooring station
- Midship mooring station
- Steering gear room
- Cargo control room
