Features
Document no.
Article no.
HP-8_ds rev.00 2005.03.15
HP-8
Technical data:
HP-8
Loudspeakers
Description:
HP-8
Horn loudspeaker for use on open deck areas, eng room etc.
WP, IP-67.
Manufacturer: DNH A/S
Material / Colour: Polyamide / RAL 7035
Mounting: Bracket or flush
Termination: 0,5m cable
Weight: 0,75 kg
IP-rating (UL Equivalent) IP-67
Max. / min. amb. temp: 150 °C / -50 °C
Impedance: 8 ohm
Rated / max. power: 8 W / 15 W
SPL 1 W / 1 m: 101 dB
SPL rated power: 110 dB
Effective freq. range: 600 - 7500 Hz
Dispersion (-6 dB)1kHz / 4kHz: 160° / 50°
Directivity factor, Q : 6,0
HP-8T:
Transformer 100V
Primary nominal tappings:
1 : 2 8,0W
2 : 3 4,0W
3 : 4 2,0W
1 : 3 1,5W
2 : 4 0,7W
1 : 4 0,4W
1= Red, 2= Yellow, 3= Green, 4= Blue
www.zenitel.biz\Communication & Security Systems\Zenitel Marine
