Tracking motion (Track Lock)
For tracking motion:
Engage all three track locks.
The skid can now track backwards and forwards in a straight line.
Steer motion (Steering Traveling)
For steer motion:
1. Position the skid so that the xed leg (with the grey knob) is in the
direction of travel.
2. Disengage the grey track lock.
3. Engage the red track locks.
4. With the xed leg of the skid facing forwards the skid can now be
moved with a ‘steering type’ motion.
Operation
x 3
All Wheels Track-
locked to a single
direction
One wheel free roation,
two track-locked
towards free wheel
