Vinten Osprey Plus - Technical Specification

28
Technical Specication
Physical Data (Studio V4170-0001)
Minimum height
666 mm (26.2 in.)
Maximum height
1485 mm (58.4 in.)
Maximum payload
70 kg (154 lb)
Weight
29.3 kg (64.6 lb)
Steering Ring Diameter
534 mm (20.8 in.)
On-shot stroke
410 mm (16 in.)
Ground clearance
19.0 mm (0.75 in.)
Transit Width
860 mm (33.8 in.)
Physical Data (OB V4170-0002)
Minimum height
678 mm (26.7 in.)
Maximum height
1497 mm (58.4 in.)
Maximum payload
70 kg (154 lb)
Weight
29.3 kg (64.6 lb)
Steering Ring Diameter
534 mm (20.8 in.)
On-shot stroke
410 mm (16 in.)
Ground clearance
31.5 mm (1.3 in.)
Transit Width
860 mm (33.8 in.)
Tracking Width
950 mm (37.4 in.)
X2
Stages
2
Max working pressure
≤ 11.7 bar (170psi)
Relief valve pressure
12 bar (187 psi)
Tracking Width
950 mm (37.4 in.)
X2
Stages
2
Max working pressure
≤ 11.7 bar (170psi)
Relief valve pressure
12 bar (187 psi)
