Final adjustment
Pan brake (Fig 6.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Pan bearing (Fig 6.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Balance mechanism bushes (Fig 6.6). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Base cover plates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Spring-loaded flap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
General
1 This section details procedures for disassembly and assembly of the Vector 70/70H head. Reference is
made in the procedures to figures in Section 6 - Illustrated Parts List.
2 The head is constructed from precision components, many of which are of aluminium alloy. Several of
the assembly procedures require the use of special tools and specific sealants, adhesives or lubricants. It is
advised that only experienced and properly equipped personnel with access to all necessary tools and
materials should attempt to overhaul, repair or replace components on these heads. The tools and
consumable materials required for work on Vector 70 heads are listed in Section 3 - Tools and Materials.
Disassembly
Platform Assembly
3 To remove the platform assembly, proceed as follows:
3.1 Remove the payload (if fitted).
3.2 Level the platform.
3.3 Referring to Fig 6.11, release the sliding plate clamp (23). Use the adjustment knob (14) to wind
the sliding plate (1) fully backwards.
3.4 Referring to Fig 6.6, remove six screws (1) securing the platform (2) to the two platform pivot
blocks (5). Lift of the platform.
3.5 The two Spirol pins (4) will remain in the platform pivot blocks, but may be removed if required.
WARNING!: To prevent damage to socket screw heads, use the correct hexagonal
wrenches and ensure that they are in good condition.
