VIPA SLIO - CCTRL_I Control word

Bit Name Function
6 STS_DO Status digital counter output (DO)
7 STS_C_DN Status set at counter direction back-
ward
8 STS_C_UP Status set at counter direction forward
9 STS_CMP* Status comparison is set when the
comparison condition is met.
If comparison is parameterized never,
the bit is never set.
10 STS_END* Status is set
when end value was reached
11 STS_OFLW* Status is set at overflow
12 STS_UFLW* Status is set at underflow
13 STS_ZP* Status is set at zero run
14 STS_LTCH Status of the latch input
15 - reserved
*) The bits remain set until reset with RES_SET (bit 6 control word).
Bit Name Function
0 CTRL_SYNC_SET activates the reset mode
1 CTRL_DO_SET enables the digital output
2 SW_GATE_SET sets the software gate
3 ...
4
- reserved
5 COUNTERVAL_SET sets counter temporarily
to the value of set value
6 RES_SET resets the bits
STS_CMP, STS_END, STS_OFLW,
STS_UFLW
and STS_ZP with edge 0-1
7 - reserved
8 CTRL_SYNC_RESET deactivates the reset mode
9 CTRL_DO_RESET disables the digital output
10 SW_GATE_RESET resets the software gate
11 ...
15
- reserved
CCTRL_I Control word
