© 2005 Directed Electronics—all rights reserved
2255
Remove the two 30-amp fuses prior to connecting these wires and do not replace them until the satellite has
been plugged into the control module. These wires are the source of current for all the circuits the relay satel-
lite will energize. They must be connected to a high current source. Since the factory supplies (+)12V to the key
switch that is used to operate the motor, it is recommended that these wires be connected there.
NNOOTTEE::
If the factory supplies two separate (+) 12V feeds to the ignition switch, connect one RED
wire of the satellite to each feed at the switch.
Connect this wire to the accessory wire in the vehicle which powers the climate control system.
Connect this wire to the ignition wire in the vehicle.
Connection for high current outputs.
Connect this wire to the second ignition wire in the vehicle. (See
Finding the Wires You Need
section.)
NNOOTTEE::
For vehicles that do not have a second ignition wire, this connection is not required.
The ribbon harness connects from the control module.
The 4-pin harness provides the capability of driving additional relays for the following:
This wire supplies a 200mA output as soon as the control module begins the remote start process. This wire can
be used to activate an immobilizer bypass unit.
This wire supplies a 200mA output. Used when the vehicle has more than one accessory wire.
OORRAANNGGEE ((--)) 220000mmAA aacccceessssoorryy oouuttppuutt
BBLLUUEE ((--)) 220000mmAA ssttaattuuss oouuttppuutt
aauuxxiilliiaarryy rreellaayy oouuttppuutt hhaarrnneessss
rriibbbboonn hhaarrnneessss
PPIINNKK//WWHHIITTEE ((++)) sseeccoonndd iiggnniittiioonn oouuttppuutt
RREEDD//WWHHIITTEE ((++)) 1122VV iinnppuutt
PPIINNKK ((++)) iiggnniittiioonn oouuttppuutt
OORRAANNGGEE ((++)) aacccceessssoorryy oouuttppuutt
RREEDD ((qqttyy 22)) ((++))1122VV iinnppuutt ffoorr hhiigghh ccuurrrreenntt oouuttppuuttss
