5522
© 2005 Directed Electronics—all rights reserved
2. The lights will flash 4-times.
3. After 1-second the car will start and the timer mode will run for the specified time period.
The system is in Timer Mode. The engine may be allowed to run for its programmed run time, or the transmitter
can be used to shut down the engine. Either way, the remote start system will restart the engine again in three
hours. Timer Mode is exited automatically after the sixth run cycle.
TToo eenntteerr oorr eexxiitt ttiimmeerr mmooddee mmaannuuaallllyy::
1. Make sure the remote start system is not operating the engine.
2. Turn the ignition on.
Timer Mode will be exited and the parking lights will flash four times.
ttaabbllee ooff zzoonneess
When using the Diagnostic functions, use the Table of Zones to see which input has triggered the system. It is
also helpful in deciding which input to use when connecting optional sensors and switches.
NNOOTTEE
: The Warn Away® response does not report on the LED.
sshhuuttddoowwnn ddiiaaggnnoossttiiccss
1. With the ignition OFF, press and
HHOOLLDD
the Valet/Program button.
2. Turn the ignition ON and then back OFF while
HHOOLLDDIINNGG
the Valet/Program button.
ttoo ppeerrffoorrmm sshhuuttddoowwnn ddiiaaggnnoossttiiccss
ZZOONNEE NNOO.. TTRRIIGGGGEERR TTYYPPEE IINNPPUUTT DDEESSCCRRIIPPTTIIOONN
1 Multiplexed Input BLUE (H1/6)
2 Multiplexed Shock Sensor Input Mux BLUE wire
3 Door Trigger GREEN (H1/5) and VIOLET (H1/7)
4 Multiplexed Shock Sensor Mux GREEN wire
5 Ignition Yellow ribbon harness wire
6 Hood Trigger GRAY on the 6-pin shutdown harness
