Viper AS4335C - Technical Parameters

INSTRUCTION FOR USE ENGLISH
8
TECHNICAL PARAMETERS
Parameter Type Units
Model
AS4335C-US
Solution tank capacity L / Gal 35 L / 9.25 Gal.
Recovery tank capacity L / Gal 35 L / 9.25 Gal.
Machine Length mm/Inches 933 mm / 36.7 Inches
Machine width with squeegee mm/Inches 570 mm / 22.4 Inches
Machine width without squeegee mm/Inches 485 mm / 19.1 Inches
Machine Height (without handle) mm/Inches 647 mm / 25.5 Inches
Machine Height (with vertical
handle)
mm/Inches 1182 mm / 46.5 Inches
Working width mm/Inches 432 mm / 17 Inches
Driving wheel diameter mm/Inches 153 mm / 6 Inches
Rear wheel diameter mm/Inches 89 mm / 3.5 Inches
Brush/Pad diameter mm/Inches 432 mm / 17 Inches
Brush/Pad pressure (max) Kg/Lbs. 19 Kg / 41.8 Lbs
Solution Flow (max) per setting L / Gal per minute
(0.59/0.69/1.11/1.68) Liters
(0.16/0.18/0.29/0.44) Gallons
Sound pressure level dB (A) 69 ± 3 dB (A)
Handle Vibration Level (max) m/s
2
< 2.5 m/s
2
Climbing capacity (max) % grade 2%
Vacuum motor power Watt / H.P. 300 W / 0.4 HP
Vacuum capacity mm/In of H
2
O 900 mm / 35.4 In of H
2
O
Brush motor power Watt / H.P. 250 Watt / 0.34 HP
Brush speed in normal mode RPM 170 RPM
IP protection class IP IP24
Voltage AC 110~120 VAC
Productivity (max) m
2
/h 1720 / 1032 m
2
/h
Machine weight with empty tanks Kg/Lbs. 64 Kg / 141 Lbs.
Gross Vehicle Weight (GVW) Kg/Lbs. 99 Kg / 218 Lbs.
Shipping Weight Kg/Lbs. 92 Kg / 203 Lbs.
Packing dimensions (L x W x H) mm/Inches (1130 x 730 x 1040 mm) / (44.5 x 28.7 x 41 Inches)
(*): Optional
