PARTS LIST
61
TABLE OF CONTENTS
GENERAL VIEW…………………………………………………………………….…………………………………………………62
AS4335C HANDLE ASSEMBLY……………………………………….…………………………………………………………..64
AS4335C RECOVERY TANK ASSEMBLY……………………………………………………….………………………………67
AS4335C SOLUTION TANK ASSEMBLY………………….…………………………………………………………………….69
AS4335C CHASSIS ASSEMBLY ..…..……..……………………………………………………………………………………..72
AS4335C &AS4325B SQUEEGEE ASSEMBLY….………………….………………………………………………………..75
AS4335C BRUSH ASSEMBLY.….…………………….…………………………………………………………………………..77
AS4335C WEAR AND TEAR PARTS …………………….…….……………………………………………………………….81
AS4335C 110-120V WIRING
DIAGRAM
.….……………………..………………………………………………………….82
* = Optional
# = Modified item No. or New Item No.
[] = Not shown
WHEN ORDERING PARTS
*Use the part numbers from the “Part. No.” columns in this parts list.
*Specify the model and serial number of the machine.
*Use the space below to record the model and serial number for future reference.
Model Serial No.
