PARTS LIST
65
AS4335C HANDLE ASSEMBLY
Kit Item Part No. Description Qty
K1 1
STICKER DROP GLUE 1
K1 2
VS15137
FRONT COVER HANDLE 1
K2 3
VS15132
RIGHT LEVER BRUSH SWITCH 1
K2 4
SPRING 1
K2/K14 5
SCREW ST4X10 5
K2 6
VS15131
LEFT LEVER BRUSH SWITCH 1
K3/K6/K7
7
SCREW ST3X16 6
K3 8
VV81432
MICRO SWITCH 1
K4 9
FIXING END OF PULLING ROD 2
K4 10
VS15133
ADJUST LEVER HANDLE 1
K4 11
WASHER 2
K4 12
PULLING ROD 1
K5 13
SPRING COMPRESSION 1
K5 14
VS15135
CONNECTION ROD 1
K5 15
VS15193
RACK 1
K6 16
CLAMP BOW 1
K7 17
CLAMP CONCAVE 1
K8 18
RUBBER SLEEVE SCREW ROD EDGE 2
K8 19
RUBBER SLEEVE SCREW ROD 2
K8/K12 20
SCREW M8*60 6
K8 21
WASHER OD15.7*ID8.5*T1.5MM 4
K9/K13 22
VS15142
DECORATION COVER HANDLE 2
K9 23
SCREW ROD M5*20 3
K9 24
WASHER ID5XOD12XT1MM 3
K9 25
VS15144
RIGHT FIXING BASE HANDLE 1
K10 26
ANTI ABRATION CIRCLE 2
K10 27
INNER FIXING CIRCLE OF GEAR 2
28
VS15192
GEAR 1
K11 29
VS15149
REAR COVER HANDLE 1
K11 30
VS15141
SEALING COVER HANDLE 1
K11/K16
31
SCREW PB5X14 20
K12 32
WASHER 2
K12 33
CONNECTION PLATE OF FIXING BASE 1
To Next Page
