PARTS LIST
70
AS4335C SOLUTION TANK ASSEMBLY
Kit Item
Part No. Description Qty
K1 1 VF80304-010 SOLUTION COVER 1
K1/K2 2 WASHER ID4*OD12*1MM 2
K1/K2 3 SCREW TA3.5X12 3
K1 4 ZIPPER 1
K2 5 INLET PIPE FRAME 1
6 VS15231 LOGO LABEL 1
7 VS15162 SOLUTION TANK 35L DARK GREY 1
K3 8 JOINTS GASKET 2
K3 9 ELBOW, 90° 2
K3 10 HOSE FRESH WATER LEVEL 1
K3 11 FLOATING BALL OF WATER LEVEL 1
K4 12 COMMUNICATION CABLE 1
K4 13
CABLE STRAIN RELIEF
1
K4 14 GASKET 1
K4 15
CABLE STRAIN RELIEF NUT
1
K5 16 VS15016 RECTIFIER 1000V 50A 1
K5 17 SCREW ST4.0X16 1
18 VS15034 CONNECTION WIRE ASSEMBLY 1
K6 19 VV81407 CIRCUIT BREAKER 4A US 2
K6 20 WATERPROOF CAP 2
K7 21 REAR COVER 1
K7 22 VS15233 CIRCUIT BREAKER LABEL 1
K7/K12 23 SCREW PWM4.0*12mm 11
K8* 24
SCREW WITH WASHER PWM4.0*14mm
2
K8* 25 BACK ACCESSORY BOX 1
K9 26 SOLUTION OUTLET COVER 1
K9 27 GASKET 1
K10 28 COUNTER WEIGHT 1
K10 29 WASHER ID6*OD18*T1.5 3
K10 30 SCREW M6X30 3
31 VS15004 MOTOR VACUUM 110~120V 60HZ 1
To Next Page
