PARTS LIST
76
AS4325B & AS4335C SQUEEGEE ASSEMBLY
Kit Item Part No. Description Qty
K4 1 VS15267 WING NUT M5 8
2 VS15109 SQUEEGEE REAR STRAP 1
3a VS15204 NR REAR BLADE NON MARKING 1
3b* VS15205 PU REAR BLADE NON MARKING 1
3c*
VS15206 LINATEX REAR BLADE 1
K1 4 SCREW TM4*12 2
K1 5 RETAINER 1
K1 6 VS15160 BEND CONNECTOR 1
K2 7 SCREW M6×40 1
K2 8 STUD 1
9 NUT M6 1
10 VS15252 SQUEEGEE TOOL 1
K3 11 NUT M5 5
K3 12
WASHER OD14.7xID5.5xT1.2mm
10
K3 13 SPACER 5
K3 14 VS15158 SQUEEGEE WHEEL 5
K3 15 SCREW M5X20 5
16a VS15201 NR FRONT BLADE NON MARKING 1
16b* VS15202 PU FRONT BLADE NON MARKING 1
16c* VS15203 LINATEX FRONT BLADE 1
17 VS15108 SQUEEGEE FRONT STRAP 1
K4 18 SCREW M5X40 4
K4 19 SCREW M5X30 2
K4 20 SCREW M5X25 2
K5 21 VS15159 SQUEEGEE KNOB 1
K5 22 SCREW M6X35 1
K1 VS15434 BEND CONNECTOR KIT 1
K2 VS15435 STUD KIT 1
K3 VS15436 SQUEEGEE WHEEL KIT 5
K4 VS15437 SQUEEGEE SCREW KIT 1
K5 VS15438 SQUEEGEE KNOB KIT 1
K6 VS15373 SQUEEGEE ASSEMBLY 1
