PARTS LIST
78
AS4335C BRUSH ASSEMBLY
Kit Item Part No. Description Qty
K1 1 SCREW M4 3
K1 2 SKIRT DECK 1
K2/K17 3 SCREW M6*40 6
K2/K17 4 VS15332 STUD 6
K2 5 PAD HOLDER 17 INCH 1
K2/K17 6 NUT M6 6
K3* 7* VF99003A RETAINER PAD 1
K3* 8* VA13477 SCREW ST4x15 3
9*
PAD 17 432MM 1
K4 10 SCREW M8x40 1
K4 11 NUT M8 1
K4 12 VF80241 PLASTIC REGULATING FULCRUM 1
K5/K13/K14 13 NUT M6 3
K5 14 VP11007 STRAIGHT MOVING ADJUSTING KNOB 1
K5 15 SCREW 1
K5 16 SPRING 1
17 VS15104 BRACKET BRUSH MOTOR 1
K6 18 SCREW M8x25 2
K6 19 WASHER ID8*OD20*T2MM 2
K6 20 SPACER 2
21 VS15000 BRUSH MOTOR 120V AC ASSEMBLY 1
22 VS15111 INLET TUBE 1
K7 23 MOTOR FIXING PLATE 1
K7 24 SCREW M6X20 4
K8/K13 25 WASHER ID6*OD18*T1.5mm 6
K8 26 SCREW M6X20 4
K9 27 VS15154 WEAR RESISTANT WASHER 2
K9 28 VS15329 ROTATION CIRCLE 1
K9 29 VS15155 SQUEEGEE ROTATION ARM 1
K10/K15/K16 30 NUT M5 3
K10/K15/K16 31 WASHER ID5*OD10*T1.0mm 4
K10 32 VS15112 LIFTING HANDLE FOR SQUEEGEE 1
K10 33 SPACER 1
