Viper AS6690T - Machine Structure (Figure 2)

INSTRUCTION FOR USE
ENGLISH
7
MACHINE STRUCTURE (as shown in Figure 2)
29. Battery connector (red)
30. Batteries (*)
31. Battery caps
32. Water level indicator tube
33. Tank safety cable
34. Vacuum system
35. Safety switch
36. Machine reverse switch
37. Recovery water drain hose
38. Security cover of charging jack
39. Squeegee lifting/lowering handle
40. Solution tank side filler cap
41. On-Board Charger (*)
(*): Optional
Figure 2
33
29
35 36 35
37
38
39
40
34
30
32
31
41
