Features
Index
Description
Operation
Applications
VHF - UHF network
VISIOdistri system
Cluster programming
Setting clusters / UHF input
Setting channels / cluster
To check the channel settings of each cluster
Level adjustment
Automatic level setting
General UHF level setting
Manual level setting
UHF input amplifier
Copy function
General reset
Technical specifications
Block diagram
p. 20
p. 21
p. 23
p. 24
p. 25
p. 27
p. 28
p. 29
p. 30
p. 31
p. 32
p. 33
p. 34
p. 34
- Designed for both digital and analogue channels,
- 6 inputs : B I-II / B III / VHF-UHF and 3 UHF inputs splitted over 10 UHF programmable clusters,
- Each cluster can have 1 to 7 channels bandwidth,
- Easy programming by using one rotary / push button viewed on 2 digits display and LEDs for each cluster
and each input,
- Unit can be locked by security code,
- 'COPY' function in order to transfer all settlements from one unit to another reducing time of installation,
- High selectivity filters,
- Low noise figure and high gain split band amplifiers,
- High power 123 dBµV,
- High UHF input levels up to 105 dBµV by switchable 20 dB input amplifier,
- Automatic leveling of signal or manual with 30 dB attenuator with 1 dB step for accurate equalization
- Selectable remote power on VHF-UHF and UHF inputs,
- -30 dB Test output.
- Powered by external power supply VNE 180.
