Vitalograph Spirotrac Instructions for Use
IFU Part No.: 07402
Issue 22
_______________________________________________________________________________________________________________
Page 64 of 78 DT_0006-15
1. Select the required session from the list.
2. Select File > Report > Test Report or select the Print/Print PDF button on the
toolbar.
4.9.6.1 Change audiometry report template
To change the default report template used:
1. Select required session from the session list.
2. Select View Audiometry button.
3. When prompted, select the required audiometry test report template from the
following:
a. For Air conduction tests, use one of the following: 01_Standard,
01_Standard_w_MCL_UCL, 06_Full_table
b. For Bone Conduction tests, use 06_Full_table
c. For Most comfortable level and UCL Uncomfortable level use
01_Standard_w_MCL_UCL
d. For SISI tests, use 05_AIR_SISI
e. For Weber tests, use 08_Weber
f. For Ear Protection tests, use 19_EarProtection_Report_AIR
4. Exit the audiometry screen. The selected report is saved with the session.
4.9.7 Shadow measurements
To compare the previous session with the current session, enable the shadow
audiogram as follows:
1. Select Tools > Options > General.
2. In Audiometry section, enable Display Reference Curve. The measurements
from the previous session for this subject will now appear as a grey background
on the graph when performing a new session.
5 Cleaning & Hygiene
5.1 Preventing Cross-Contamination of Subjects
A spirometer is not designed or supplied as a ‘sterile’ device.
Vitalograph intends that a new Bacterial Viral Filter (BVF) be used for every subject to
prevent cross contamination. Using a new BVF provides a significant level of
protection of for the subject, the device and the user against cross contamination
during spirometry manoeuvres.
Refer to the Vitalograph website for instructions on ‘Cleaning and Hygiene’.
6 Fault Finding Guide
Problem Fault Symptoms: • Not measuring flow
