Vitec Multimedia MGW Ace Decoder OG - Audio Output Routing

MGW Ace Decoder OG
User Manual, Version 2.0 36
Parameter Description
Output
Resolution
(for each
channel)
Select the required resolution from the drop-down list.
If the input stream is not using a standard video resolution, the output video
resolution is 720p60 by default.
SDI1-A/B
/ HDMI
SDI2 /
Composite
Enable video outputs when the box is selected.
SDI2 can be configured as part of the Primary channel (HD/SD) or
Secondary channel (SD).
HDMI color space can be chosen between YUV, RGB
Display
Format
Select the preferred display from the drop-down list.
Aspect
Ratio
Select the aspect ratio from the drop-down list. When "Auto" is selected the
aspect ratio is determined according to the aspect ratio of the incoming
stream parameter (planned for next versions).
To set Audio Settings:
This section sets audio routing for:
 SDI1-A/B, SDI2 and HDMI outputs
 Digital AES 1 and 2 unbalanced outputs. It is possible to set if AES or S/PDIF format is
outputted (respectively Consumer or Professional).
 Analog Balanced and Unbalanced audio outputs. The volume can be adjusted
independently for the audio analog balanced and unbalanced output.
