Page 55 of 81
6 Loc3-10Tx Transmitter
Press the “+” key to enter the Receiver Link menu.
RECEIVER LINK
ENABLE
BACK
Press the “+” or “-” key to highlight the “ENABLE” option, then press the “F” key to start the process. The display will show the
message “WAIT” until setup is complete.
An ID number-will now be displayed at the bottom of the screen for identication purposes.
RECEIVER LINK
DISABLE
BACK
88=6b=Of=84=5b=b4
The transmitter is now waiting to connect to a receiver.
Either press the “I” button or use the “+” and “-“ keys to highlight “BACK” then “F” key to exit back to the main screen.
When in the main screen a “beacon” icon will be displayed on the right hand side. When the icon is ashing the transmitter
is waiting to connect to a receiver. The ashing will stop when successfully connected to the receiver. If no icon is visible this
indicates that the Receiver Radio Link has not been activated.
83.1 kHz
L 2
While the icon on the transmitter is ashing, indicating that it is waiting to connect to a receiver, switch on the vLoc3-Pro receiver
and enter the user menu by pressing and holding the information button. Scroll down the menu options until Transmitter Link is
highlighted.
NOTE: The transmitter and receiver sides of the radio links can be switched on in any order.
Menu
Imp/Metric
Continuous info.
GPS source
Bluetooth Pairing
Transmitter Link
Transmitter Control
Meter
Off
Internal
Transmitter Link
Transmitter Link Disabled
To Next Page
