– 7 –
ITEM LABEL DESCRIPTION SEE PAGE:
1.
IR transmitter Transmits signals to projector
2.
Status LED Lights when the remote control is used
3.
Laser Press to operate the on-screen pointer
4.
Up Up arrow when connected through USB to a PC (Not available in this series)
5.
Right Right arrow when connected through USB to a PC (Not available in this series)
6.
Down Down arrow when connected through USB to a PC (Not available in this series)
7.
Page Down Page down when connected through USB to a PC (Not available in this series)
8.
Up cursor
9.
Right cursor
10.
Down cursor
Navigates and changes settings in the OSD
16
11.
Volume +/- Adjusts volume
15
12.
Mute Mutes the built-in speaker
13.
Zoom+ Zoom in
14.
Zoom- Zoom out
15.
Freeze Freeze/unfreezes the on-screen picture
16.
Blank Makes the screen blank
17.
Source Detects the input device
18.
Auto Auto adjustment for phase, tracking, size, position
19.
Menu Opens the OSD
16
20.
Status Opens the OSD Status menu (the menu only opens when an
input device is detected)
36
21.
Keystone top/bottom Corrects image-trapezoid (wider top/bottom) effect
14
22.
Left cursor Navigates and changes settings in the OSD
23.
Enter
Changes settings in the OSD
24.
Page Up Page up when connected through USB to a PC (Not available
in this series)
25.
Left Left arrow when connected through USB to a PC (Not avail-
able in this series)
26.
Enter Enter key when connected through USB to a PC (Not avail-
able in this series)
16
27.
Power Turns the projector on or off
11
28.
Laser Use as on-screen pointer. DO NOT POINT IN EYES.
