Vivotek FD8161 User Manual

VIVOTEK
User's Manual - 11
Ready to Use
1� Access the Network Camera on the LAN�
2� Retrieve live video through a web browser or recording software�
Adjusting the Lens
Based on the live image retrieved from the camera, adjust the camera lens by doing the
following:
To adjust the viewing angle
1� Loosen the pan adjustment screw and then turn the lens module left and right� Upon
completion, tighten the screw�
2� Loosen the tilt adjustment screws on both side of the camera and then turn the lens module
up and down� Upon completion, tighten the screws�
3� Loosen the rotation adjustment screw and then turn the lens to adjust the image orientation�
Upon completion, tighten screw�
Rotate the screw
Turn the lens
Audio In
1 2 3 4
AV Out
ON
Int. NTSC
1 2
Ext PAL
Audio In
1 2 3 4
AV Out
ON
Int. NTSC
1 2
Ext PAL
Audio In
1 2 3 4
AV Out
ON
Int. NTSC
1 2
Ext PAL
2
3
1
Loosen Tighten
Loosen
Tighten
Loosen
Tighten
Pan 350°
Rotate 350°
Tilt 85°
