Audio Settings
Mute: Select this option to disable audio transmission from the Network Camera to all clients� Note that
if mute mode is turned on, no audio data will be transmitted even if audio transmission is enabled on the
Client Settings page� In that case, the following message is displayed:
Internal microphone input gain: Select the gain of the internal audio input according to ambient
conditions� Adjust the gain from +21 db (most sensitive) ~ -33 db (least sensitive)�
External microphone input: Select the gain of the external audio input according to ambient conditions.
Adjust the gain from +21 db (most sensitive) or -33 db (least sensitive)�
Audio type: Select audio codec AAC, GSM-AMR, and G�711�
■ AAC provides good sound quality at the cost of higher bandwidth consumption. The bit rates are
selectable from: 16Kbps, 32Kbps, 48Kbps, 64Kbps, 96Kbps, and 128Kbps�
■ GSM-ARM is designed to optimize speech quality and requires less bandwidth. The bit rates are
selectable from: 4�75Kbps, 5�15Kbps, 5�90Kbps, 6�7Kbps, 7�4Kbps, 7�95Kbps,10�2Kbps, and
12�2Kbps�
■ G.711 also provides good sound quality and requires about 64Kbps. Select pcmu or pcma mode.
When completed with the settings on this page, click Save to enable the settings�
NOTE
► The Network Camera offers two inputs to capture audio - internal microphone or external microphone.
The internal/external microphone switch is located on the back panel of the Network Camera.
