VIVOTEK
194 - User's Manual
7.36 Exposure window setting per channel
Group: exposurewin_c<0~(n-1)> for n channel products <product dependent>
(capability_videoin_supportexpwin = 1)
NAME VALUE DEFAULT
SECURITY
(get/set)
DESCRIPTION
mode auto, custom, blc auto 4/4
The mode indicates how to decide
the exposure.
auto: Use full view as the only
one exposure window.
custom: Use inclusive and
exclusive window.
blc: Use BLC.
win_i<0~9>_enable <boolean> 0 4/4 Enable or disable the window.
win_i<0~9>_policy 0~1 0 4/4
0: Indicate exclusive.
1: Indicate inclusive.
win_i<0~9>_home (0~320, 0~240) (110,80) 4/4
Left-top corner coordinate of the
window.
win_i<0~9>_size (0~320, 0~240) (100x75) 4/4 Width and height of the window.
Group: exposurewin_c<0~(n-1)>_profile for m profile and n channel product
(capability_videoin_supportexpwin = 1)
NAME VALUE DEFAULT
SECURITY
(get/set)
DESCRIPTION
i<0~(m-1)>_mode auto, custom,
blc
auto 4/4
The mode indicates how to
decide the exposure.
auto: Use full view as the
only one exposure window.
custom: Use inclusive and
exclusive window.
blc: Use BLC.
i<0~(m-1)>_win_i<0~9>_enabl
e
<boolean> 0 4/4 Enable or disable the window.
i<0~(m-1)>_win_i<0~9>_policy 0~1 0 4/4
0: Indicate exclusive.
1: Indicate inclusive.
i<0~(m-1)>_win_i<0~9>_home (0~320, 0~240) (110,80) 4/4
Left-top corner coordinate of
the window.
i<0~(m-1)>_win_i<0~9>_size (0~320, 0~240) (100x75) 4/4
Width and height of the
window.
